BPP Series Cylindrical Photoelectric Sensor Connector Type – M12 4-Pin, Through-Beam 15M / Retro 5M / Diffuse 3M, NPN PNP, IP67
BPP series cylindrical photoelectric sensor, connector type — three methods in one M12 4-pin nickel-plated brass body: through-beam 15M/10M, retro-reflective 5M, diffuse 3M/300mm/100mm. NPN/PNP matrix, visible red light, 1ms response, sensitivity adjuster, Light ON/Dark ON via control wire. 12-24VDC, IP67, reverse & short-circuit protected. 1:1 Balluff/IFM/P+F drop-in. BXUAN factory direct.
- Overview
- Related Products
| Model | NPN Output | BPP-QO15M | BPP-QO10M | BPP-KO5M | BPP-CO3M | BPP-CO30 | BPP-CO10 |
| PNP Output | BPP-QR15M | BPP-QR10M | BPP-KR5M | BPP-CR3M | BPP-CR30 | BPP-CR10 | |
| Sensing method | Through-beam | Retro-Reflection | Diffuse Reflection | ||||
| Sensing Range | 15M | 10M | 5M | 3M | 300mm | 100mm | |
| Sensing target | Opaque materials, translucent materials | ||||||
| Hysteresis | ≤20% of Sensing Range | ||||||
| Response time | Max. 1ms | ||||||
| Sensitivity adjustment | YES (Adjuster) | ||||||
| Operation mode | Light ON mode - Dark ON mode selectable (Control wire) | ||||||
| Indicator | Visible red light | ||||||
| Power supply | 12-24 VDC ±10%(ripple P-P: 10%) | ||||||
| Current consumption | ≤45mA | ||||||
| Control output | NPN open collector output / PNP open collector output model | ||||||
| Load voltage | ≤30V DC | ||||||
| Load current | ≤200mA | ||||||
| Residual voltage | NPN:1VDC , PNP:2.5 VDC | ||||||
| Protection circuit | Reverse power protection circuit, output short overcurrent protection circuit | ||||||
| Insulation resistance | ≤20 MΩ(500 VDC megger) | ||||||
| Noise immunity | ± 240 VDC the square wave noise (pulse width: 1 μs) by the noise simulator | ||||||
| Dielectric strength | 1,000 VAC~ 50/60 Hz for 1 min | ||||||
| Vibration | 1.5 mm double amplitude at frequency of 10 to 55 Hz (for 1 min) in each X, Y Zdirection for 2 hours | ||||||
| Ambient illuminance (receiver) | Sunlight:≤11,000 lx, incandescent lamp: ≤3,000 lx | ||||||
| Ambient temperature | -10 to 60 ℃, storage: -25 to 75 ℃ (no freezing or condensation) | ||||||
| Ambient humidity | 35 to 85 %RH, storage: 35 to 85 %RH (no freezing or condensation) | ||||||
| Protection rating | IP67 | ||||||
| Connection | connector type | ||||||
| Cable spec. | M12 connector 4PIN | ||||||
| Material | Case: Brass, Ni-plate | ||||||
| Sensing part: PC lens | |||||||
